Peugeot 205 Manual

Dimensions and weights
Reference / Dimensions and weights


Reugeot 205
Reugeot 205

Note: All figures are approximate, and may vary according to model. Refer to manufacturer’s data for exact figures.

Dimensions
Overall length . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3705 mm Overall width:
Basic, GL, GE and Van . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1562 mm
All other models except Cabriolet . . . . . . . . . . . . . . . . . . . . . . . . . . . 1572 mm
Cabriolet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1589 mm Overall height . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1372 to 1381 mm Wheelbase . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2420 mm Front track:
All models except SR, GT, Cabriolet and GTI . . . . . . . . . . . . . . . . . . 1350 mm
SR and GT models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1364 mm
1.6 GTI and Cabriolet models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1392 mm
1.9 GTI models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1383 mm Rear track:
All models except SR, GT, Cabriolet and GTI . . . . . . . . . . . . . . . . . . 1300 mm
SR and GT models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1314 mm
1.6 GTI and Cabriolet models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1328 mm
1.9 GTI models . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1344 mm Weights
Kerb weight* . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 740 to 935 kg Maximum towing weight:
TU9 and TU1 engines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 700 kg
All other engines . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 800 kg Maximum roof rack load . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50 kg
*Exact kerb weight varies depending on model - refer to VIN plate for details Length (distance)
Inches (in) x 25.4 = Millimetres (mm) x 0.0394 = Inches (in) Feet (ft) x 0.305 = Metres (m) x 3.281 = Feet (ft) Miles x 1.609 = Kilometres (km) x 0.621 = Miles Volume (capacity)
Cubic inches (cu in; in3) x 16.387 = Cubic centimetres (cc; cm3) x 0.061 = Cubic inches (cu in; in3)
Imperial pints (Imp pt) x 0.568 = Litres (l) x 1.76 = Imperial pints (Imp pt) Imperial quarts (Imp qt) x 1.137 = Litres (l) x 0.88 = Imperial quarts (Imp qt) Imperial quarts (Imp qt) x 1.201 = US quarts (US qt) x 0.833 = Imperial quarts (Imp qt)
US quarts (US qt) x 0.946 = Litres (l) x 1.057 = US quarts (US qt) Imperial gallons (Imp gal) x 4.546 = Litres (l) x 0.22 = Imperial gallons (Imp gal)
Imperial gallons (Imp gal) x 1.201 = US gallons (US gal) x 0.833 = Imperial gallons (Imp gal)
US gallons (US gal) x 3.785 = Litres (l) x 0.264 = US gallons (US gal) Mass (weight)
Ounces (oz) x 28.35 = Grams (g) x 0.035 = Ounces (oz) Pounds (lb) x 0.454 = Kilograms (kg) x 2.205 = Pounds (lb) Force
Ounces-force (ozf; oz) x 0.278 = Newtons (N) x 3.6 = Ounces-force (ozf; oz) Pounds-force (lbf; lb) x 4.448 = Newtons (N) x 0.225 = Pounds-force (lbf; lb) Newtons (N) x 0.1 = Kilograms-force (kgf; kg) x 9.81 = Newtons (N) Pressure
Pounds-force per square inch x 0.070 = Kilograms-force per square x 14.223 = Pounds-force per square inch (psi; lbf/in2; lb/in2) centimetre (kgf/cm2; kg/cm2) (psi; lbf/in2; lb/in2) Pounds-force per square inch x 0.068 = Atmospheres (atm) x 14.696 = Pounds-force per square inch
(psi; lbf/in2; lb/in2) (psi; lbf/in2; lb/in2) Pounds-force per square inch x 0.069 = Bars x 14.5 = Pounds-force per square inch
(psi; lbf/in2; lb/in2) (psi; lbf/in2; lb/in2) Pounds-force per square inch x 6.895 = Kilopascals (kPa) x 0.145 = Pounds-force per square inch
(psi; lbf/in2; lb/in2) (psi; lbf/in2; lb/in2) Kilopascals (kPa) x 0.01 = Kilograms-force per square x 98.1 = Kilopascals (kPa) centimetre (kgf/cm2; kg/cm2) Millibar (mbar) x 100 = Pascals (Pa) x 0.01 = Millibar (mbar) Millibar (mbar) x 0.0145 = Pounds-force per square inch x 68.947 = Millibar (mbar)
(psi; lbf/in2; lb/in2)
Millibar (mbar) x 0.75 = Millimetres of mercury (mmHg) x 1.333 = Millibar (mbar) Millibar (mbar) x 0.401 = Inches of water (inH2O) x 2.491 = Millibar (mbar) Millimetres of mercury (mmHg) x 0.535 = Inches of water (inH2O) x 1.868 = Millimetres of mercury (mmHg) Inches of water (inH2O) x 0.036 = Pounds-force per square inch x 27.68 = Inches of water (inH2O)
(psi; lbf/in2; lb/in2)
Torque (moment of force) Pounds-force inches x 1.152 = Kilograms-force centimetre x 0.868 = Pounds-force inches
(lbf in; lb in) (kgf cm; kg cm) (lbf in; lb in) Pounds-force inches x 0.113 = Newton metres (Nm) x 8.85 = Pounds-force inches (lbf in; lb in) (lbf in; lb in) Pounds-force inches x 0.083 = Pounds-force feet (lbf ft; lb ft) x 12 = Pounds-force inches
(lbf in; lb in) (lbf in; lb in) Pounds-force feet (lbf ft; lb ft) x 0.138 = Kilograms-force metres x 7.233 = Pounds-force feet (lbf ft; lb ft) (kgf m; kg m)
Pounds-force feet (lbf ft; lb ft) x 1.356 = Newton metres (Nm) x 0.738 = Pounds-force feet (lbf ft; lb ft) Newton metres (Nm) x 0.102 = Kilograms-force metres x 9.804 = Newton metres (Nm) (kgf m; kg m)
Power
Horsepower (hp) x 745.7 = Watts (W) x 0.0013 = Horsepower (hp) Velocity (speed)
Miles per hour (miles/hr; mph) x 1.609 = Kilometres per hour (km/hr; kph) x 0.621 = Miles per hour (miles/hr; mph) Fuel consumption*
Miles per gallon (mpg) x 0.354 = Kilometres per litre (km/l) x 2.825 = Miles per gallon (mpg)
Temperature
Degrees Fahrenheit = (°C x 1.8) + 32 Degrees Celsius (Degrees Centigrade; °C) = (°F - 32) x 0.56
* It is common practice to convert from miles per gallon (mpg) to litres/100 kilometres (l/100km), where mpg x l/100 km = 282
